The KY-024 Linear Magnetic Hall Effect Sensor Module with Analog and Adjustable Digital Output for Arduino is an advanced workshop sensor designed for measuring magnetic field strength and detecting…
The KY-024 Linear Magnetic Hall Effect Sensor Module with Analog and Adjustable Digital Output for Arduino is an advanced workshop sensor designed for measuring magnetic field strength and detecting magnetic polarity. Built around a linear Hall sensor core paired with an onboard potentiometer, it allows users to monitor precise variations in magnetic flux as well as trigger custom threshold events.
The module features dual output modes: an analog output (AO) that supplies a voltage proportional to the strength of the magnetic field, and a digital output (DO) driven by an LM393 comparator whose switching threshold can be precisely calibrated using the onboard tuning potentiometer. Onboard status LEDs indicate power connection and magnetic trigger events for effortless debugging.
| Sensor Architecture | Linear Hall-effect sensing element combined with an LM393 voltage comparator |
|---|---|
| Dual Output Options | Continuous Analog (AO) voltage output and threshold-triggered Digital (DO) switch output |
| Sensitivity Control | Onboard precision trimming potentiometer to adjust the digital trigger threshold level |
| Operating Voltage | 3.3V to 5V DC compatible with Arduino, ESP32, and standard microcontroller logic |
| Status Indicators | Dual LEDs displaying power status and active magnetic field detection |
What is the operating voltage?
3.3V to 5V DC compatible with Arduino, ESP32, and standard microcontroller logic.
Is it compatible with Arduino and ESP32?
Yes. It works with Arduino, ESP32 projects.
