The 12x12x12mm Tactile Push Button Switch-10Pcs. is a set of large, high-durability momentary Single Pole Single Throw (SPST) push button switches engineered for clear, physical actuation feedback… 12x12x12mm.
The 12x12x12mm Tactile Push Button Switch-10Pcs. is a set of large, high-durability momentary Single Pole Single Throw (SPST) push button switches engineered for clear, physical actuation feedback and reliable long-term performance. Featuring a 12mm x 12mm square base with a 12mm overall height, these switches provide a larger touch surface compared to standard miniature tactile buttons.
Each switch includes four through-hole PCB/breadboard pins, internally linked in pairs to deliver strong mechanical anchoring on circuit boards and simplified trace routing. The elevated 12mm actuator profile makes these switches ideal for mounting behind panel cutouts, project boxes, and custom enclosures.
These switches are widely used as reset buttons, mode selectors, user input keys, and power control triggers. They are fully compatible with 3.3V and 5V microcontroller boards such as Arduino, ESP32, Raspberry Pi, PIC, AVR, as well as breadboards and custom PCBs.
| Switch Type | Momentary Tactile Push Button Switch (SPST - Normally Open) |
|---|---|
| Dimensions | 12mm x 12mm Body x 12mm Overall Height |
| Actuator Color | Black / Square Cap Compatible |
| Terminal Count | 4 Pins (Through-Hole DIP) |
| Package Quantity | Pack of 10 Pieces |
| Contact Rating | DC 12V @ 50mA |
| Contact Resistance | ≤ 50 mΩ |
| Insulation Resistance | ≥ 100 MΩ at 250V DC |
| Operating Force | ~160g – 260g (Distinct tactile snap) |
| Size | 12x12x12mm |
Is it compatible with Arduino and ESP32?
Yes. It works with Arduino, ESP32, Raspberry Pi, STM32 projects.
Can I buy the 12x12x12mm Tactile Push Button Switch-10Pcs. in Kanpur?
Yes – buy online with delivery across India, or pick it up from the iTechBuilders store, Damodar Nagar, Kanpur.
