The 6x6x11mm Tactile 4 Pin RED Push Button Switch (Pack of 10) is a set of standard momentary Single Pole Single Throw (SPST) tactile micro switches featuring a distinct 11mm tall actuator shaft… 6x6x11mm.
The 6x6x11mm Tactile 4 Pin RED Push Button Switch (Pack of 10) is a set of standard momentary Single Pole Single Throw (SPST) tactile micro switches featuring a distinct 11mm tall actuator shaft topped with a red button head. Designed to make temporary electrical contact when pressed and return to an open state when released, these switches provide clear, crisp tactile feedback.
Housed in a standard 6mm x 6mm square body, each switch features four through-hole PCB/breadboard pins (internally connected in pairs to enhance mechanical stability and simplify trace routing). The extended 11mm height allows the red actuator button to extend cleanly through custom project enclosures and control panels.
These tactile switches are ideal for reset buttons, user input interfaces, breadboard prototyping, mode selectors, and DIY electronic projects. They are fully compatible with Arduino, ESP32, Raspberry Pi, PIC, AVR, stripboards, and custom printed circuit boards (PCBs).
| Switch Type | Momentary Tactile Push Button Switch (SPST - Normally Open) |
|---|---|
| Dimensions | 6mm x 6mm Body x 11mm Overall Height |
| Actuator Color | Red |
| Terminal Count | 4 Pins (Through-Hole DIP) |
| Package Quantity | Pack of 10 Pieces |
| Contact Rating | DC 12V @ 50mA |
| Contact Resistance | ≤ 100 mΩ |
| Insulation Resistance | ≥ 100 MΩ at 250V DC |
| Operating Force | ~160g – 250g (Tactile feedback) |
| Size | 6x6x11mm |
Is it compatible with Arduino and ESP32?
Yes. It works with Arduino, ESP32, Raspberry Pi, STM32 projects.
Can I buy the 6x6x11mm Tactile 4 Pin RED Push Button Switch in Kanpur?
Yes – buy online with delivery across India, or pick it up from the iTechBuilders store, Damodar Nagar, Kanpur.
