The 6 x 6 x 8mm Tactile Pushbutton is a set of standard momentary Single Pole Single Throw (SPST) tactile micro switches featuring an 8mm overall height topped with a distinct blue button head. 6 x 6 x 8mm.
The 6 x 6 x 8mm Tactile Pushbutton is a set of standard momentary Single Pole Single Throw (SPST) tactile micro switches featuring an 8mm overall height topped with a distinct blue button head. Designed to make momentary electrical contact when pressed and instantly return to an open state upon release, these switches deliver crisp, tactile feedback.
Housed in a standard 6mm x 6mm square body, each switch is equipped with four through-hole PCB/breadboard pins (internally connected in pairs to provide mechanical stability and streamline trace layout). The 8mm height offers a low-profile actuator position suitable for compact custom enclosures, user interfaces, and control panels.
These versatile push buttons are ideal for reset switches, mode selection, user input triggers, and prototyping. They are fully compatible with 3.3V and 5V microcontroller platforms including Arduino, ESP32, Raspberry Pi, PIC, AVR, stripboards, and custom printed circuit boards (PCBs).
| Switch Type | Momentary Tactile Push Button Switch (SPST - Normally Open) |
|---|---|
| Dimensions | 6mm x 6mm Body x 8mm Overall Height |
| Actuator Color | Blue |
| Terminal Count | 4 Pins (Through-Hole DIP) |
| Package Quantity | Pack of 10 Pieces |
| Contact Rating | DC 12V @ 50mA |
| Contact Resistance | ≤ 100 mΩ |
| Insulation Resistance | ≥ 100 MΩ at 250V DC |
| Operating Force | ~160g – 250g (Tactile feedback) |
| Size | 6 x 6 x 8mm |
Is it compatible with Arduino and ESP32?
Yes. It works with Arduino, ESP32, Raspberry Pi, STM32 projects.
Can I buy the 6 x 6 x 8mm Tactile Pushbutton in Kanpur?
Yes – buy online with delivery across India, or pick it up from the iTechBuilders store, Damodar Nagar, Kanpur.
