Unmanned Ground Surveillance Vehicle (UGSV) Army Robo
The Unmanned Ground Surveillance Vehicle (UGSV) is a robotic vehicle designed for remote monitoring, surveillance, and navigation. It provides an excellent platform for students and beginners in robotics and IoT to learn about motor control, wireless communication, and obstacle detection. With real-time camera integration and sensor modules, UGSV is ideal for security and defense-inspired projects.
“UGSV helps beginners explore robotics by combining motor control, sensors, and wireless navigation into a single project.”
Why Build a UGSV?
- Beginner-friendly robotics project
- Uses Arduino/ESP32 for motor & sensor control
- Wireless control via Wi-Fi or Bluetooth
- Obstacle detection using ultrasonic sensors
- Camera integration for live surveillance
Key Features for Beginners
- Motor Driver (L298N/L293D) for wheel control
- Ultrasonic sensor for obstacle detection
- Wi-Fi/Bluetooth module for remote navigation
- Rechargeable battery-powered mobility
- Camera module (optional) for surveillance
UGSV Hardware Basics
The UGSV hardware setup consists of DC motors with a motor driver, ultrasonic sensor, and microcontroller. It can be controlled wirelessly via a mobile app or joystick, making it perfect for security and monitoring applications.
Beginner Modules
- DC Motors with motor driver
- Ultrasonic sensor for obstacle detection
- Bluetooth/Wi-Fi module for wireless control
- Camera module for live video streaming
- Rechargeable battery pack
Quick Specs
- Motor Driver: L298N / L293D
- Sensor: HC-SR04 Ultrasonic
- Microcontroller: Arduino Uno / ESP32
- Wireless: Bluetooth HC-05 / ESP32 Wi-Fi
- Power: 7.4V – 12V Battery Pack
First Project: Basic Motor & Obstacle Detection
The Basic UGSV Project moves the vehicle forward and stops if an obstacle is detected within a set distance. This introduces motor control and ultrasonic sensing.
Connections:
- DC Motors ? Motor Driver L298N ? Arduino/ESP32
- Ultrasonic Sensor (HC-SR04) ? Arduino Pins (Trig, Echo)
- Bluetooth/Wi-Fi module ? Arduino Serial Pins
- Battery Pack ? Motor Driver + Controller
Code:
// UGSV: Motor + Ultrasonic Obstacle Detection
#define trigPin 9
#define echoPin 10
#define motor1 5
#define motor2 6
long duration;
int distance;
void setup() {
pinMode(trigPin, OUTPUT);
pinMode(echoPin, INPUT);
pinMode(motor1, OUTPUT);
pinMode(motor2, OUTPUT);
Serial.begin(9600);
}
void loop() {
// Measure distance
digitalWrite(trigPin, LOW);
delayMicroseconds(2);
digitalWrite(trigPin, HIGH);
delayMicroseconds(10);
digitalWrite(trigPin, LOW);
duration = pulseIn(echoPin, HIGH);
distance = duration * 0.034 / 2;
if (distance > 20) { // Safe distance
digitalWrite(motor1, HIGH);
digitalWrite(motor2, LOW); // Move Forward
} else {
digitalWrite(motor1, LOW);
digitalWrite(motor2, LOW); // Stop
}
delay(200);
}
Learning Outcomes:
- Understand motor control using L298N driver
- Learn obstacle detection with ultrasonic sensors
- Combine motors and sensors in a single project
- Build a beginner-level robotic surveillance vehicle
Next Steps & Applications
After the basic model, learners can enhance UGSV with camera live streaming, GPS tracking, and IoT dashboards. Applications include border surveillance, disaster response, and security patrol robots.
Get Started with UGSV at iTechBuilders
iTechBuilders provides UGSV robotics kits, tutorials, and guidance for students, schools, and hobbyists. Whether you are a beginner or advancing in robotics, we offer DIY kits, workshops, and project mentorship. Contact us to kickstart your UGSV journey today!
